CL opamps do not model input common mode range

Created by	signality
Created	November 21, 2013
Last modified	November 21, 2013
Tags	opamp

Summary

CL opamps do not model input common mode range!

Simulate > Time Domain > Run Time-Domain Simulation

incorrectly shows that Vout still represents the +/-10V
difference between two inputs with a 100V common mode voltage.
