Seems to work great. We haven't talked about shifters in class yet, but I see the purpose. Have you found any way to change the number of inputs when placing the muxes? I searched around a bit, but I could only find two-input. I guess you could string them together if you needed more, but it would be a bit of a mess and not very intuitive since the selector lines would have to be routed all over the place.

by joelmathewson
March 09, 2012

I asked the CircuitLab devs if they are going to add an option to change the amount of inputs for gates and they said it is on their list of things to do. As of right now you have cascade like you described.
